Height Adjustment One-touch Spline Controller
Adjustment increments Minimum 0.1 mm step
-
Angle adjustment 120° - 180° - 210°
-
Usage Shaving of weld bead outside of the pipe(length direction)
-
Shaving range Width: 25 mm, Height: -5 mm ~ +6.5 mm
-
Size Dimension of between guide plat: 32mm
O/D of milling head : 35mm
-
Weight 8.4 kg
-
Power 1700W (or 1400W)
-
Inserts 3EA CFWB110350
Application Non-ferrous metal, Steel, other materials
