Wireless universal transmitter
4 - 20 mA | WAL-3500
Desin Instruments
WAL-3500
4-20 mA Signals Repeater between local and remote stations by WiFi
Up to 20 signals 4-20 mA in any direction
WiFi 2.4 GHz
The WAL-3500 Systems are based on wireless devices destined to retransmit (recopy) remote mV or mA signals by WiFi Local Network 2.4 GHz with 40 mW output power.
Appropriate to reproduce mA current loops and logic signals in a remote system, from the corresponding inputs in a local system.
Analog signal repeaters by standard WIFI 802.11b
A mA signal variation in one input of the local module is exactly reproduced in a mA output of the remote module
16 dBM typical transmissión power
Antenna\'s connection by RP-SMA connector
Up to 15 km with external antenna under appropriated conditions
Standard version from 2 up to 20 signals total
Version to retransmit signals in both directions
Enclosure in DIN rail mounting or optional IP65 enclosure for field mounting
Power supply 85...265 Vac or 12 / 24 Vdc (option)
