Diesel engine TCD 2015 V06 (Agri)
6-cylinderturbochargedfor agricultural applications

diesel engine
diesel engine
diesel engine
Add to favorites
Compare this product


Characteristics

Type
diesel
Number of cylinders
6-cylinder
Technology
turbocharged
Product applications
for agricultural applications
Cooling system
air cooling
Emissions level
Tier 3, Euro 3
Other characteristics
compact
Power

360 kW
(489.464 hp)

Torque

2,080 Nm
(1,534.1293 ft.lb)

Rotational speed

Min.: 600 rpm
(3,769.91 rad.min-1)

Max.: 2,100 rpm
(13,194.69 rad.min-1)

1,300 rpm
(8,168.14 rad.min-1)

Displacement

11.9 l
(3.144 gal)

Weight

1,020 kg
(2,248.72 lb)

Length

985 mm
(38.8 in)

Width

932 mm
(36.7 in)

Height

1,141 mm
(44.9 in)

Description

Engine for agricultural machinery. V-engine with 90° angle. Extremely compact and powerful with high power density. Electronic injection system controlled via solenoid valves. Tried, tested and proven technology, equipped with acoustically optimised components
