Single-phase electric energy meter DHZ 5/65

DIN railmulti-function

Measuring devices are used to detect residual currents or current consumption levels. Energy counters (current or electricity meters) generally detect the amount of active power consumed in total. The digital energy counters of series DHZ are directly measuring counters and detect the active energy in alternating current networks. The detected power value can be easily viewed via the multifunction LC display or can be further processed via the standardised S0 pulse output. The devices are highly accurate and are verified. The DHZ 5/65-4 S0 is a digital, verified speed counter for detecting active energy in 4-wire networks. The display is switched by a control key even for the display test and the version display. Features: rated current: 5 (65) A, rated operating voltage: 3 x 230 / 400 V AC, verified design, accuracy class 1 (1%) as per IEC 1036, S0 output as per DIN 43864, generously dimensioned terminals, 6 module width units wide
