VHF transceiver / infrared / for touch probes
SE 540, SE 640, SE 642 DR. JOHANNES HEIDENHAIN GmbH

{{requestButtons}}

Characteristics

  • Network:

    VHF, infrared

  • Applications:

    for touch probes

Description

Area of application
In the mating hole
In the spindle
In working space of machine
In the machine's working space; for common communication with TS and TT 449 using infrared transmission
Input/output signals
Square-wave signals at HTL level
Start signal R
Ready signal B
Trigger signal S
Battery warning W
Square-wave signals at HTL level
Start signals R(-TS) and R(-TT)
Ready signals B(-TS) and B(-TT)
Trigger signals S and S
Battery warning W
