EBR-PN: handle with pneumatic drive
Material:
Glass-fibre reinforced polyamide based (PA) technopolymer. Resistant to solvents, oils, greases and other chemical agents.
Colour:
Grey-black, matte finish.
Push button:
Light-blue technopolymer, glossy finish.
Caps:
Technopolymer, grey-black colour, matte finish. Supplied assembled, removable by a screwdriver.
Standard executions:
Brass bosses, threaded blind hole.
EBR-PN-3/2-NO: the pneumatic valve is normally open. The actuation of the button stops the air passage.
EBR-PN-3/2-NC: the pneumatic valve is normally closed. The actuation of the button opens the air passage.
EBR-PN-5/2: the actuation of the button switches the output channel of the air, between the two available.
The handle is supplied with quick couplings for direct fitting of a tube Ø 4 mm for pneumatics.
The handle allows the direct drive of a single-acting pneumatic actuator (execution 3.2) or double acting (execution 5.2). The force to be applied to the button for the actuation of the drive is independent from the operating pressure.
The handle is already set up with discharge function of the pressure chamber.
