slurry pump / with electric motor / centrifugal / high-performance
EGM-6S Excellence Pump Industry Co.,Ltd.

{{requestButtons}}

Characteristics

  • Media:

    slurry

  • Operation:

    with electric motor

  • Type:

    centrifugal

  • Other characteristics:

    high-performance, multi-stage, high-efficiency, chemical-resistant, wear-resistant, for harsh environments, cantilevered, handling, for harsh environments, for desulfurization, for abrasive fluids, for marine dredging

  • Flow:

    Max.: 1,008 m³/h (35,597.1841 ft³/h)

    Min.: 468 m³/h (16,527.264 ft³/h)

  • Head:

    Max.: 94 m (308'04")

    Min.: 20 m (65'07")

  • Power:

    Max.: 560 kW (761.39 hp)

    Min.: 0 kW (0 hp)

Description

Models of Excellence's EGM Series of centrifugal slurry pumps are standard cantilevered, horizontal slurry pumps, engineered for handling operations of abrasive and high-density slurries. These pumps are integrated with frame plate liners and impellers, manufactured out of metal materials that deliver wear resistance capabilities. They feature either gland shaft seals or expeller shaft seals, and discharge branches that can be positioned on to 8 different positions (dependent on installation and application requirements).

Aside from slurry management functions, the EGM series may also be used in several fields of application, including metallurgical, mining, coal, power, generation, and construction material industries. The pumps are capable of being installed in multi-stage series.
