Eyelet pliers GIGA

precisionrugged

The manual clamp eyeleting machine GIGA in stainless steel, allows the application with minimal effort all the eyelets used for packaging (7-9-051, etc.), it is also possible to apply the large eyelets for towels and banners from 31 VL to 80 VL Technical features: Dimensions mm.30x200x300 Weight Gr. 1300. Eyelets used: Type 7-9-051 - VL large eyelets from 31 to 50 VL and from 60 to 80 VL (with appropriate inserts). Eyelets 7-9-051 The eyelets type 7-9 and 051 are eyelets which do not require pre-drilling to be inserted. To use these eyelets have to buy only the clamp with beater. Large eyelets VL from 31 to 80 The large eyelets VL are greater than the standard eyelets for packaging. They are used on towels and banner ads. To insert an eyelet must first mount on the caliper the drill kit to make a pilot hole and then apply the eyelet by inserting the kit pounding. The punches are interchangeable with ease and at the time the order is necessary to specify which type of eyelet you want use. The eyelets must be entered manually on the punch. They are suitable for low production.
