Screw compressor GEA Grasso 5HP
airelectricstationary

screw compressor
screw compressor
screw compressor
Add to favorites
Compare this product


Characteristics

Technology
screw
Type
air
Power source
electric
Portability
stationary
Application domain
industrial
Other characteristics
compact, axial
Pressure

30 bar, 50 bar
(435.11 psi, 725.19 psi)

Flow

101 m³/h, 135 m³/h, 168 m³/h, 202 m³/h
(3,566.78 ft³/h, 4,767.48 ft³/h, 5,932.86 ft³/h, 7,133.56 ft³/h)

Power

Min.: 88 kW
(119.65 hp)

Max.: 555 kW
(754.59 hp)

Length

883 mm, 919 mm
(35 in, 36 in)

Width

861 mm, 943 mm
(34 in, 37 in)

Height

718 mm, 768 mm
(28 in, 30 in)

Weight

552 kg, 633 kg
(1,217 lb, 1,395.5 lb)

Description

The extremely low volume flow in relation with the cooling capacity makes this series to a big performer. CO₂ (freezing) The 50 bar GEA Grasso 5HP compressor has been developed for use in CO₂ cascade freezing systems and is a well-accepted and reliable appearance in the industrial refrigeration market. 4 single stage models from 3 up to 6 cylinders cover a wide range of capacities. The extremely low volume flow in relation with the cooling capacity makes this series to a big performer. NH3 (heat pump applications) A logic further development of the GEA Grasso 5HP Series is the integration in NH₃ heat pump systems. The 50 bar design makes it possible to condensate up to 80ºC and results in producing high level of water temperatures. Heat pump systems are developing very quickly in various segments of industry (dairy, slaugtherhouses etc.) and contribute in reducing waste heat as well as CO₂ emissions Features of GEA Grasso 5HP Series Compact nodular cast iron compressor housing Heavy duty axial roller bearing Special design gas tight shaft seal Counter pressure independent overflow valve Capacity control steps per cylinder Suitable for speed control (500 - 1,500 min-1)
