chemical pump / electric / self-priming / peristaltic
Hei-FLOW Precision 01 Heidolph Instruments GmbH & Co. KG

{{requestButtons}}

Characteristics

  • Media:

    for chemicals

  • Operation:

    electric

  • Priming:

    self-priming

  • Type:

    peristaltic

  • Domain:

    laboratory

  • Other characteristics:

    chemical-resistant, corrosion-proof, small, variable-speed, transfer, handling, process, filling, metering

  • Flow:

    Max.: 0.813 l/min (0.2148 us gal/min)

    Min.: 0 l/min (0 us gal/min)

Description

Reproducibility - pumping and dosing

- Flow rates of 0.38 - 813 ml/min with single-channel pump heads
- Multi-channel flow rates from 0.005 - 364 ml/min
- This pump drive is suitable for multi-channel operation
- Low speed range from 5 - 120 rpm

- Control speed (rpm), direction and On/Off function via analog interface for 0 – 10 V or 4 – 20 mA or digital RS 232 interface
- Flow characteristic of pump heads in combination with various tubing diameters is pre-programmed for accurate flow rate numbers
- Digital read-out of:
- Speed (rpm)
- Tubing diameter
- Flow rate in ml/min
- Dosing volume
- Interval dosing
- Pause function
- Easily change all process parameters via control buttons
- These models connect to an optional foot-pedal remote control via cable to start and stop your pump drive outside a closed fume hood increasing your personal safety and superior ease of use in multiple sample fills
- These models feature electronic speed control at an accuracy of ± 0.5 %
- A press of the max button accelerates the filling and draining of your tube
- At the press of a button the pump operates clockwise or counter-clockwise
- Calibrate your flow volume and flow rate individually
