Coding position -
External thread plug-in side - M23 x 1
Flange - 25 x 25 mm
Hole diameter - 4 x Ø 2,7 mm
Hole distance - 19.8 mm
Housing type - Panel
Insert - RJ45
Installation type Flange,Front wall
Length (L) - 19 mm
Locking type - Screw connection
Material housing - brass,Zinc Die Cast
Material housing surface - Nickel
Material seals/o-rings - FKM (FPM),NBR
Protection class - IP 67,IP 69 K
Seal type - O-Ring
Shield - unshielded
suitable contact inserts -
7MRJ450007,
A7RJ-081M41,
A7RJ-081M6A,
A7RJ-821M51
Temperature range - -40°C to +125°C
Panel hole - Ø 23 + 0,1 mm
Housing without contact inserts
Electrical data depend on the RJ45 version used
Incl. soldering insert 8-pole
M23 RJ45 Accessories
