3-roller plate bending machine / hydraulic / CNC


  • Number of rollers:


  • Operation:


  • Other characteristics:


  • Sheet thickness:

    Min.: 20 mm

    Max.: 100 mm


Hydraulic 3 rolls plate bending machine with pre-bending
Useful lenght from 2000 up to 4000 mm
Thickness from 20 up to 100 mm
The machine is fully hydraulic
Robust frame worked with CNC machines
Size of the hydraulic system and components, including hydraulic pistons, higher than necessary to reduce the pressures of work and have a longer life
Movement on linear guides
3 hydraulic motors coupled to planetary gear for rotation of the three rolls
Automatic compensation of the peripherical speed of the top roll
Hardened rolls
Extended shafts to use section bending dies for some models
Separate control desk on wheels
Push buttons control parallel movement of lateral rolls and rotation
Hydraulic opening of shoulder by control desk
Management of lateral rolls parallelism through proportional valve and PLC
Hydraulic inclination of lateral rolls for conical bending directly from control desk through selectors
Nr.4 digital readouts
Nr. 3 rotation speeds
