Programming software NX Mold Design

designdevelopmentverification

NX Mold Design is the ultra-modern software solution for the optimisation of the tool development process. From the component design, through tool construction, to the validation of the design and tools – the module simplifies all the stages of the process. Shortened lead times and a faster response to design modifications are just two of the possibilities it opens up. Increased productivity and quality Validation and verification of tools and design Accelerated mould construction process Fewer tool design errors Reduction in the CNC programming time With the module it is possible to automatically generate and optimise the mould core and cavity from the part model. The resulting components are inspected by means of a variety of verification functions for the continuing process, in order to detect and deal with errors from the start. By incorporating factory standards and standard structures as well as available libraries, you can design your mould structure according to your standards. The associativity between the part design and the mould construction becomes a matter of course with the NX software. The shortening of the modification process achieved in this way enables you to guarantee competitiveness in the market. Data import of 3D models from other systems or NX Creation of models and implementation of design modifications Comprehensive mould base, standard parts, component systems and mould structures Reuse of factory standards Automated creation of parts lists, drawings, project data structures and NX tool paths Inspection of a part for suitability for production using verification functions Development of mould core and cavity Automation of the design of tools
