metal slip ring / hyperfrequency / IP65
LPHF-03A JINPAT Electronics Co., Ltd.

{{requestButtons}}

Characteristics

  • Material:

    metal

  • Other characteristics:

    hyperfrequency, IP65

  • Rotational speed:

    60 rpm (377 rad.min-1)

  • Number of contacts:

    3 unit

Description

Part Number: LPHF-03A

3circuits

Interface: SMA-f (50Ω); Frequency Range: 0~3Hz
VSWR (max): 1.3, 2, 2
Peak Power (max): 1kW*
Insertion Loss (max) 0.4db, 0.7db, 0.4db
Insertion Loss WOW (max) 0.1dB, 0.2dB, 0.2dB

Working Speed: 0~60rpm; Weight: 0.7kg
Isolation (min): 60db
Starting Torque (max): 10Ncm

Working Temperature: -30℃~+70℃; 95%RH; IP56

Life (min): 10×106 revolutions
