electric slip ring / 380V AC/DC / hyperfrequency / for harsh environments
LPHF-WG01B JINPAT Electronics Co., Ltd.

{{requestButtons}}

Characteristics

  • Type:

    electric

  • Other characteristics:

    380V AC/DC, hyperfrequency, for harsh environments

  • Rotational speed:

    60 rpm (377 rad.min-1)

  • Voltage:

    380 V

  • Number of contacts:

    1 unit

Description

Part Number: LPHF-WG01B

Interface Type: UBR 120‐UBR
Frequency Range :13.75‐14.5 GHz
VSWR (max) :1.20
Insertion Loss (max): 0.25 dB
VSWR-WOW: 0.05
Insertion Loss -WOW: 0.05 dB
Peak Power (max): 3000 W
Average Power (max): 750 W

Working Speed: 60 rpm; Housing: Aluminum; Starting Torque: 50 Ncm
Continuous Rotational Torque: 50 Ncm; Weight: 240g

Working Temperature:‐30 ℃~+60℃, ‐40℃ ~ + 70℃(Storage); IP40;
Humidity:95%RH;

Life: 20 million turns
