water rotary union / for air / multi-passage / hydraulic
LPT000-0402-02A JINPAT Electronics Co., Ltd.

{{requestButtons}}

Characteristics

  • Medium:

    for water, for air

  • Number of passages:

    multi-passage

  • Applications:

    hydraulic, pneumatic

  • Other characteristics:

    compact

  • Rotational speed:

    Min.: 0 rpm (0 rad.min-1)

    Max.: 150 rpm (942 rad.min-1)

Description

Part Number: LPT000-0402-02A

4 circuits

Current Range: 4 circuits* signal; Voltage: 56 V;
Dielectric Strength: ≥ 300 VAC@50 Hz; Insulation: 200 MΩ@500 VDC;
Electrical Noise:≤70 mΩ;

Working Speed:0~150 RPM; Wire Size: AWG24 Teflon®UL; Wire Length: rotor(300 mm), stator(300 mm);
Contact: Precious metal; Housing: Aluminum alloy;

Temperature: -20℃~+60℃; Humidity: up to 60%RH; IP 54;
