solid-shaft slip ring / multi-channel / rugged / hyperfrequency
LPHF‐02C JINPAT Electronics Co., Ltd.

{{requestButtons}}

Characteristics

  • Construction:

    solid-shaft

  • Other characteristics:

    multi-channel, rugged, hyperfrequency

  • Rotational speed:

    200 rpm (1,257 rad.min-1)

  • Current:

    0.5 A

  • Voltage:

    24 V

  • Number of contacts:

    2 unit

Description

Part Number: LPHF-02C

2 channels

Interface Type: SMA Female
Frequency Range :DC to 18 GHz
VSWR (max) :1.35@0 - 8 GHz, 1.5@8 - 18 GHz; 2.0
Insertion Loss (max): 0.4 dB @ 0 to 8 GHz, 1.0 dB @ 8 to 18 GHz ; 1.0 dB
VSWR-WOW: 0.01, 0.5
Insertion Loss -WOW: 0.06 dB, 0.40 dB
Peak Power (max): 1000 W
Average Power (max): 50 W@18 Hz
Phase-WOW (max): 0.5° dB @ 0 to 8 GHz, 1.0° dB @ 8 to 18 GHz; 4° dB @ 0 to 8 GHz, 10° dB @8 to 13 GHz
Isolation min: 50 dB

Working Speed: 200 rpm; Starting Torque: 50 Ncm

Working Temperature:‐40 ℃~+70℃, ‐50℃ ~ + 70℃(Storage);
Humidity:95%RH;

Life: 10 million turns
