Electric slip ring LPT158-0405through-holefor rotary tablesfor wrapping machines
Add to favorites
Compare this product
Characteristics
- Type
- electric
- Construction
- through-hole
- Applications
- for rotary tables, for wrapping machines
- Material
- metal
- Other characteristics
- IP54
- Voltage
Max.: 380 V
Min.: 0 V
- Primary current
Max.: 5 A
Min.: 0 A
- Rotational speed
Max.: 300 rpm
(1,885 rad.min-1)Min.: 0 rpm
(0 rad.min-1)- Number of channels
Max.: 4 unit
Min.: 1 unit
Description
Part Number: LPT158-0405
Circuits: 4 circuits * 5A
Working Voltage: 380VAC
Dielectric Strength: Between circuits≥1000V@50Hz
Insulation: 500MΩ@500VDC
Electrical Noise: ≤70mΩ (50rpm)
Working Speed:0~300 rpm
Through Hole: φ158mm
Contact: Precious Metal
Wire Size:AWG22# (0.35mm²)Tin plated Teflon UL
Temperature: -20°C~+60°C
Humidity:≤60%RH
IP54
