Ultrasonic flow meter DUK
for liquidsin-linedigital

ultrasonic flow meter
ultrasonic flow meter
Add to favorites
Compare this product


Characteristics

Technology
ultrasonic
Fluid
for liquids
Installation
in-line
Other characteristics
digital
Volumetric flow rate

Min.: 0.1 l/min
(0 us gal/min)

Max.: 630 l/min
(166.4 us gal/min)

Process temperature

Min.: 0 °C
(32 °F)

Max.: 120 °C
(248 °F)

Process pressure

Min.: 0 bar
(0 psi)

Max.: 16 bar
(232.06 psi)

Description

The DUK series Ultrasonic flowmeters work on the principle that the speed of an ultrasonic wave transmitted through a flowing medium is hampered when the flows are in opposite direction. DUK setup includes two ultrasonic transmitters/receivers placed opposite to each other and at an angle to the medium whose flow is to be measured/monitored. Under no-flow conditions, waves from both the terminals traverse at the same speed. However, under flowing conditions, the wave traversing against the medium is at a disadvantage. A microprocessor-based control system accurately calculates the difference in speed between the two waves and after processing provides the medium’s flow rate. DUK is ideal for measuring, monitoring, metering, and dosing of low-viscosity fluids.

Catalogs

DUK-C
DUK-C
7 Pages
