Fixed crane Liftliner 4000

cable systemforestrylifting

LIFTLINER The innovative Skyline Crane System LIFTLINER 4000 With the new radio controlled skyline crane Liftliner 4000 it is possible to operate the functions “load up/down” and „moving the crane“ at the same time. Therefore one can work very efficient and careful when thinning the forest, and also it is possible, to place the trees exactly on the desired spot at the offloading point. Because of the separate winch for the load, the mainline cable is fixed on the carriage and has the duty to pull the carriage. Therefore the carriage without clamps Liftliner 4000 works without wear on the skyline and mainline. LIFTLINER Details manually switchable skyline clamp with aluminium pads double receiver radio control KONRAD strong winch with big cable capacity exit for cable backwards for flat terrain exit for cable downwards for standard use control system Konrad with engine management high performance diesel engine double castor wheels for a smooth running over a support Liftliner 4000 SkylineD 20 mm / D 20 mm Haul-in-cableD 12 mm comp. 85 m Winch pulling capacity40 kN (4 to) EngineVW 100 HP Weight950 kg Carriage remote controlKONRAD KFS 16 Carriage controlKONRAD
