Absolute rotary encoder Sendix M5863
magnetic24-bitmulti-turn

absolute rotary encoder
absolute rotary encoder
Add to favorites
Compare this product


Characteristics

Type
absolute
Technology
magnetic
Absolute encoder resolution
24-bit
Construction
solid-shaft, multi-turn, flange
Output signal
SSI
Protection level
standard, robust, IP65
Other characteristics
high-resolution
Housing diameter

58 mm
(2.28 in)

Shaft diameter

6 mm, 10 mm
(0.24 in, 0.39 in)

Description

Energy Harvesting Technology: Electronic multiturn encoders. The Sendix M5863 absolute encoder with Energy Harvesting Technology and SSI interface is an electronic multiturn encoder without gears and without battery - in standard format with 58 mm flange. Due to its high robustness and high resolution, it is ideally suited for use in demanding applications. Benefits Cables and connectors Highest robustness Robust bearing construction in safety-Lockplus™ design for particularly high resistance. Extra large bearings. Mechanically protected shaft seal. Wide temperature range from -40°C to +85°C. Energy Harvesting Technology without gears and without battery. Applications Angular measurement deviation ±0,5°. Repeat accuracy ±0.2°. Short control cycles, clock frequency at SSI up to 2 MHz. Resolution max. 38 bit (14 bit ST + 24 bit MT).
