The basic machine for ergonomic grinding of smaller parts and lot sizes
The EBS-Compact is designed for grinding welded edges, corners and surfaces of smaller components. By easy replacement of the grinding belt the machine is rapidly changed between roughing and finishing process.
The compact design allows the integration of the machine into existing production areas. The main advantage is the easy and ergonomic grinding with the maximum quality by the precise Kuhlmeyer-technology and experience.
Technical data / Standard dimension:
Table size: 1500 x 500 mm
Workpiece weigh: Max. 30 kg
Table movement horizontal manually: 530 mm
Vertical lifter stroke motorized: 480 mm
Footprint dimensions: 2400 x 1850 x 2000 mm
Extraction flange and volume: Ø 150 mm und 1500 m³/h
Adjustable belt speed: 4 -25 m/s
Grinding belt dimension: 100 x 4745 mm
Features:
Quick changing of abrasive belts for roughing and finishing
Triangular configuration for excellent access to and visibiloity oft he working area
Pneumatic belt tensioning adjustable
Adjustable grinding belt speed
Swivel grinding belt up to 90° with perfect belt centering
Table height adjustment with soft start ramp
Self-centering of grinding belt
Easy opening of belt cover
Smooth moving prism rollers for table, contact pressure tools and table height adjustment
Enhanced safety by safety switches and E-Stop-button
Free swiveling pressure tool
Pressure roller adaptable with a quick coupling
Single Belt Grinding Unit EBSC with options
Additional carriage with Deburring Unit
Unit with flange diameter 125 mm and quick connection for different brushing heads
Drive motor with 0,37 kW and 1500 rpm
Rubber layer on the table
