Automatic stencil printer STP-350 / STP-550
solder pasteSMT

automatic stencil printer
automatic stencil printer
automatic stencil printer
automatic stencil printer
Add to favorites
Compare this product


Characteristics

Control
automatic
Number of colors
solder paste
Applications
SMT

Description

Specifications: l Made of stainless steel, great workmanship. l STP-350 Working area: 18"x13", frame thickness should be less than 1.5". l STP-550 working area: 23"x17", frame thickness should be less than 1.5". l Max. X direction adjustment: 5/8". l Max. Y direction adjustment: 5/8". l Max. Z direction adjustment: 5/8". l θ adjustment 10°. l Open end, fit any framed stencils as long as the paste area is smaller than the base. l Circuit board mount kit included, capable of two side boards. l Use framed stencils. Stencil and frame not included. They are customer items. l Weight: STP350, 60 lb
