DC voltage transducer DVT-100
DIN rail

DC voltage transducer
DC voltage transducer
Add to favorites
Compare this product


Characteristics

Electrical characteristics
DC
Other characteristics
DIN rail
Voltage

Min.: 1 V

Max.: 100 V

Description

DVT-100 DC Voltage Transducer DIN Rail-Mounted Isolated DC Voltage Transducer The DVT-100 DC Voltage Transducer is designed to convert a 1-100 DC Voltage input to either a 4-20mA output or a voltage standard output that is proportional to the input. It is also perfect for solar-string voltage monitoring. The DC Voltage Transducer provides effective and safe isolation between the input and output. DVT-100 DC Voltage Transducer Features: •Primary voltage DVT-100: 100-1000 Vdc •Output 4-20mA, 0-1Vdc, 0-5Vdc •Accuracy: 1% over range •Linearity: 0.5% over range •Response time: 10.0 mSec •Working Range: 0-120% •Overload: 150% continuous •Temperature: -30 degrees C to 70 degrees C operating •Humidity: 90% operating •Isolution: 4.5KV, 1 Minute •Supply voltage: 15-48 Vdc
