Power chuck MBS/L
6-jawprecisionself-contained

power chuck
power chuck
Add to favorites
Compare this product


Characteristics

Type
automatic
Number of jaws
6-jaw
Other characteristics
precision, self-contained, diaphragm
Rotational speed

Max.: 8,000 rpm
(50,265.48 rad.min-1)

Min.: 3,000 rpm
(18,849.56 rad.min-1)

Gripping force

Max.: 12,486 kgf

Min.: 232 kgf

Outer diameter

Max.: 294 mm
(12 in)

Min.: 80 mm
(3 in)

Description

Design Self-contained design with built-in air cylinder. Air is supplied to the chuck by a multi passage air tube assembly with a rotary coupling. Coolant through the spindle capability is standard. Application OD and ID chucking for cylindrical grinding, turning, and hard turning. Ideal for workpieces requiring high concentricity, and/or close round ness. Ideal for fragile parts which are easily distorted, and applications requiring high spindle speeds.
