Forward travel vibratory plate VD 20 P

gasoline engine

Compared to our others series of forward vibratory plates, plates of PRACTIC series are fully customizable even at the motor level. Thanks to the exciter with frequency of 100 Hz these machines can be used for compaction of most types of material while maintaining excellent stability, controllability and work performance. Thanks to the frame construction a number of manipulation points are accessible from all sides of machine. Operational parameters Plate width 500 mm Centrifugal force 20 kN Frequency 100 Hz Max. speed 25 m/min Engine Maker and type Honda GX 160 Fuel Petrol Net power 3,6 kW Emission stage EU Stage V Operational fluids Water tank capacity 12 l Working dimensions Lenght 1110 mm Width 500 mm Height 1005 mm Transport dimensions Lenght 750 mm Width 500 mm Height 925 mm
