Ball valve ITEM 445leverfor waterpetroleum
Add to favorites
Compare this product
Characteristics
- Type
- ball
- Operation
- lever
- Media
- for water, petroleum
- Body
- flange, stainless steel
- Applications
- industrial, for the chemical industry, for the food industry, for oil industry applications, for the pharmaceutical industry, for automobiles, for the gas industry, for water treatment, for marine applications, for the mining industry, for shipbuilding, for the paper industry, for machine tools, power line, turbine
- Number of channels
- 3-way
- Associated function
- reducing
- Other characteristics
- ISO, ATEX
- DN
Max.: 100 mm
(3.937 in)Min.: 15 mm
(0.591 in)- Pressure
Max.: 40 bar
(580.2 psi)Min.: 16 bar
(232.1 psi)- Temperature
Max.: 150 °C
(302 °F)Min.: -20 °C
(-4 °F)
Description
Macro Ball valves
Category Other stainless steel ball valves
3-way flat body flanged stainless steel ball valve “L” port, reduced bore.
GENERAL FEATURES:
• General specifications: EN 1792
• (“FIRE SAFE” conforming to EN ISO 10497; API 607 V. ed. on request)
• Intercepted fluid: water, petroleum products, petrochemicals and other aggressive liquids.
• Reduced bore.
ON REQUEST:
• Seals made of: PTFE glass filled, PTFE with carbon graphite
• “T” port , see mounting plan
• For other applications, please contact our technical department.
CERTIFICATIONS:
• ATEX version in conformity with European Directive 2014/34/EU.
• ATEX certificate on request.
