Differential pressure flow meter FX-1130for fuelin-line
Add to favorites
Compare this product
Characteristics
- Technology
- differential pressure
- Fluid
- for fuel
- Installation
- in-line
- Process temperature
Max.: 40 °C
(104 °F)Min.: 0 °C
(32 °F)- Process pressure
Max.: 1.96 bar
(28.43 psi)Min.: 0 bar
(0 psi)
Description
The FX Series gravity flow detectors employ a precision differential pressure transducer to detect liquid level variations in a measuring cylinder. The detectors are capable of measuring instantaneous and cumulative fuel flow.
Applicable Fluids Gasoline, Light Oil, Kerosene
Measurement Range 0 to 50 g/s
Accuracy ± 0.2% of reading, ± 0.01% FS
Instantaneous Resolution 0.01 g/s
Cumulative Resolution 0.1 g
Max. Cumulative Qty 1000 g
Max. Pressure 196 kPa
Operating Temperature 0 to +40 deg C
Weight Approx. 13 kg
Catalogs
FP/FX/FZ Series Detectors
16 Pages
