Instrumentation amplifier / wide-band / high-gain
Pasternack Enterprises, Inc.

Characteristics

  • Secondary function:

    instrumentation

  • Other characteristics:

    wide-band, high-gain

  • Power:

    Min.: 1 W (0 hp)

    Max.: 2 W (0 hp)

Description

Pasternack high gain wideband amplifiers (A.K.A. high gain broadband) from Pasternack provide radio frequency amplification in wide band of frequencies with high gain. High gain wideband amplifiers are ideal for defense, EW/ECM, radar, test instrumentation, telecom, satcom, microwave radio and industrial applications that benefit from wide band amplification. These high gain wideband amplifiers range in frequencies from 2 to 18 GHz depending on the RF amp configuration.

The Pasternack high gain wideband amplifier product line's excellent performance is achieved by using a hybrid microwave integrated circuit design with advanced GaAs pHEMT technology. These high-gain wideband amplifier modules are unconditionally stable and include built-in voltage regulation, bias sequencing and reverse bias protection for added reliability. Pasternack wide band / broadband high gain amplifiers have over-voltage protection that is installed externally for easy repair. This class of wideband high gain amplifiers is fully matched internally for 50 Ohm input and output which eliminates the need for any additional sensitive external radio frequency tuning components.

High gain wideband amplifiers from Pasternack are housed in hermetically sealed modules and have operating temperatures from -55°C to +85°C. This comprehensive wide band high gain RF amp product offering provides a choice of gain levels, frequency ranges and power outputs that meet many requirements. Pasternack is commitmented to excellence in RF high gain wide band amplifiers which means we stock a wide variety of high quality amplification products for immediate shipment worldwide.
