Polyamide cable gland EPN 705 series

nickel-plated brassbrassEMC-shielded

This EMC / EMI cable gland is designed to ground cable braids directly to the wall with optimum contact to the periphery of the gland base. Built-in twisting protection, wide sealing and clamping range. Rapid EMC connection of the cable shield through contact spring inside gland body and the electric potential of the installation. An additional improvement of the equipotential bonding and the vibration protection can be improved further by using our EPN 715 hexagon nut with cutting edges obtained. Cable glands play an important part in safeguarding EMC requirements where cables and leads enter into a shielding system. They must ensure a durable permanent connection with very small Ohm‘s and inductive resistance between the cable shield and the housing potential. Our QUICK-FIT EMC cable glands fulfill these requirements in an outstanding way. The assembly of the type EPN 705 succeeds simply and fast: 1. Partially expose the braid by removing the outer sheath of the cable of approximately 10 mm. 2. Insert the cable through the domed nut and the gland body until the contact spring is pressed against the braided screen. 3. Firmly screw on domed nut. 4. Due to this principle it is possible to conduct the braided screen of the EMC cable through the entire gland body up to the clamping are of the inner wires. An additional improvement of the equipotential bonding and the vibration protection can be improved further by using our EPN 715 hexagon nut with cutting edges obtained. Material : Brass, nickel plated Blade insert : Polyamide PA6 V-2 Sealing ring : Polychloroprene-Nitrile rubber CR/NBR O-Ring : Nitrile rubber NBR Protection grade : IP68
