pneumatic curbstone laying clamp



  • Type:


  • Load:

    160 kg (352.7 lb)


Lays all kerbstones with bald surface (concrete, granite) up to 160 kg

Adaptable on all hydraulic vehicles with fixed forks, with a flow from 20L/min up to 130L/min thanks to the adjustable flow divider

12 V electric supply for the hydraulic turbine and mast inclination

Suction pipe 2m long, with 360° rotation

5 different suction cups for all kerbstones : P1 - P2 - P3 - T1 - T2 - T3 - T4 - AC1 - AC2 - A1 - A2 - CC1 - CC2 - T2 - T3 - CS1 - CS2 - CS3.

Suction cup with 360° rotation and 4 locking positions

Hydraulic control lifting/lowering by handles

Automatic tilting adjustment of the mast

Silent and ergonomic machine, perfect for city work

Shaft with 4 axles for a perfect perpendicularity when lifting

Dust cleaning system with filter

Safety : vacuum gauge + adjustable brake for the arm rotation

Option : thermal engine
