Standard slip ring SR011IP65
Add to favorites
Compare this product
Characteristics
- Other characteristics
- standard, IP65
- Voltage
Max.: 250 V
Min.: 0 V
- Primary current
Max.: 7 A
Min.: 0 A
- Rotational speed
5,000 rpm
(31,416 rad.min-1)- Number of channels
Max.: 36 unit
Min.: 4 unit
Description
The SR011 series slip ring offers sealing to IP65 standard for the SR003 type packaged slip ring. These sealed slip rings can be built using the standard components of the SR003 type unit with a very minimum lead time required.
Insulation Resistance: >200MΩ at 500 VDC.
Hipot: 500 VAC for 15 seconds (all combinations).
Electrical Noise: Better than 10 mΩ - speed dependent.
Different numbers of rings to those shown.
Changes to drive/mounting to customer requirements.
Higher current & voltage capacity per ring.
Higher IP ratings available.
Termination type & length to customer requirements.
Alternative contact materials for specific applications.
