SR008 type packaged slip rings were designed primarily for low voltage, signal applications being run at low to medium speeds. The assembly has a small through bore for concentric shaft mounting or for the passage of fluid or gas lines.
Insulation Resistance: >200MΩ at 500 VDC.
Hipot: 500 VAC for 15 seconds (all combinations).
Electrical Noise: Better than 10 mΩ - speed dependent.
Different numbers of rings to those shown.
Changes of shaft mounting to customer requirements.
Higher current & voltage capacity per ring.
Internally modified to customer requirements.
Termination type & length to customer requirements.
