Incremental rotary encoder SCH68 serieshollow-shaftIP65heavy-duty
Add to favorites
Compare this product
Characteristics
- Type
- incremental
- Construction
- hollow-shaft
- Protection level
- IP65
- Other characteristics
- heavy-duty
- Housing diameter
68 mm
(2.68 in)
Description
SCH68B
Diameter:
68 mm (through hollow bore)
Resolution:
up to 12,500 ppr
Shaft:
ø 16 mm to ø 1 inch.
Temperature:
-40° C to 85° C (operating)
SCH68F
Diameter:
68 mm
Resolution:
up to 12,500 ppr
Shaft:
ø 20 mm and ø 1 inch.
Temperature:
-40° C to 85° C (operating)
SCH68DW
Diameter:
68 mm (through hollow bore w/ adaptor)
Resolution:
up to 12,500 ppr
Shaft:
ø 20 mm and ø 1 in.
Temperature:
-40° C to 85° C (operating)
