Adsorption compressed air dryer DRY-DAT 120

adsorption compressed air dryer
adsorption compressed air dryer
Add to favorites
Compare this product


Characteristics

Technology
adsorption
Capacity

133 l/min
(35.13 us gal/min)

Description

Dew point-dependent control system with digital display Pressure dew point can be preset easily LED function displays on the front of the switch cabinet for: power, adsorption, regeneration and economy cycle Potential-free output With prefilter and downstream filter Air dried consistently to a pressure dew point of -40 °C for a high degree of process reliability and perfect working results Energy-saving with only 12 pressure changes per hour for max. regeneration air requirements of 14.3 % Longer service life: Collecting chamber within the moist zone protects the drying agent from concentrated moisture Technical details GTIN/EAN - 4011666803825 Article number - DGKH604012 Flow rate at pressure dew point -40°C - 133 l/min Weight - 9 kg Air outlet - 1/4"i Dimensions (WxDxH) - 312x210x390 mm
