Compatible for 1 phase 2 wire, 3 phase 3 wire, 3 phase 4 wire systems
11 to 300V (L-N), 19 to 519V (L-L) measurement
Accuracy of ± 0.5% for voltage & current, 0.1% for Frequency, 0.01% for PF, 1% for Power, Class 1 for Active, reactive & Apparent energy
Max/Min power Demand measurement, Import/Export Energy measurement
%THD upto 31st level, RS485 Communication MODBUS RTU
CE, UL , MID certified
Specifications
Display Type - LCD with Backlight, Bargraph Representation for Current
Display Configuration - 4 Rows of 4 Digits, 1 Row of 8 Digits
Electrical Connection - 3Ø - 3W, 3Ø - 4W, 2Ø - 3W, 1Ø - 2W
Type of Output - Pulse Output
Features - %THD upto 31st Level, Max/Min Demand (Power), Max Demand Current, Phase Sequence Detection
Communication Protocol - RS485 and MODBUS RTU
CT Primary - 1 / 5A to 10kA (Programmable for Any Value)
CT Secondary - 1 / 5A ( Programmable )
PT Primary - 100V to 500kV (Programmable for Any Value)
PT Secondary - 100V to 500V (Programmable for Any Value)
Rated Input Current - Nominal 5A AC (Min - 11mA Max - 6A)
Supply Voltage - 85 to 270V AC (45/65 Hz)
Size - 96 x 96mm
Mounting Type - Panel Mount
Certification - CE, UL , MID
