rotary arm stretch wrapper / automatic / pallet / stretch film
T1650FZ | CE,UL,ISO SHANDONG SINOLION MACHINERY CORP LTD

{{requestButtons}}

Characteristics

  • Type:

    rotary arm

  • Operating mode:

    automatic

  • Product applications:

    pallet

  • Other characteristics:

    stretch film

  • Rotational speed:

    Max.: 15 rpm (94 rad.min-1)

    Min.: 3 rpm (19 rad.min-1)

  • Height:

    2,200 mm

  • Width:

    1,200 mm

  • Length:

    1,200 mm

Description

1. Technology data:

Max load size: 1200 (L)×1200(W) ×2200(H)mm
Packing efficiency: 20-40 loads / hour
Rotary arm speed: 3-15rpm
Height of turntable: 78mm
Power supply: 1.5KW 380V 50HZ 3Phase
Max load capacity: 2000kgs
Wrapping requirement: Bottom wrapping up to 2/3 of pallet, top wrapping 15cm higher than the height of pallet
Working ambiance: Indoor, normal temperature
Options:Turntable diameter: 1800mm;Turntable height;Color

2. Wrapping material
Stretch wrapping film: Core size: 3’’
Film width: 750mm
Diameter: max 260mm
Thickness: 20-35μm
One roll stretch film to be supplied along with machine for trial running

3. Utility:
Compressed air
Pressure: 0.5-0.6 MPa
Dew point: +2-+10℃ (7bar, +2-+10℃)
Air consumption: 1000ml/min

4. Supply scope
4.1 rotating turntable 1set
4.2 tower with film carriage 1 set
4.3 Film feeding & cutting device 1set
4.4 control system 1set

5. Main electrical parts
PLC, screen, relay& inverter: Schneider
Button & indicating light: APT
Breaker: Schneider
Motor: Chinese brand
Photoeye: Panasonic
Pneumatic component: FESTO
