Single-axis inclinometer HCA516T
digitalTTLMEMS

single-axis inclinometer
single-axis inclinometer
single-axis inclinometer
single-axis inclinometer
single-axis inclinometer
single-axis inclinometer
single-axis inclinometer
single-axis inclinometer
single-axis inclinometer
single-axis inclinometer
Add to favorites
Compare this product


Characteristics

Number of axes
single-axis
Output
digital, TTL
Technology
MEMS
Other characteristics
high-precision, anti-vibration, IP67
Inclination

Min.: 1 °

Max.: 90 °

Resolution

0.001 °

Description

HIGH PRECISION DIGITAL INCLINOMETER Single-Axis Inclinometer Wide voltage input: 9~36V Wide temperature working: -40~+85℃ Highly anti-vibration performance >2000g IP67 protection class Product Description HCA516T is a high accuracy inclinometer launched by RION company, inherit the stability of the SCA series, while the accuracy be effectively improved, and the temperature drift performance with much more excellence , in addition the system with built-in high-precision 16bit A / D differential converter, meanwhile through 5 filtering algorithm, which can measure the angle of sensor output relative to the horizontal tilt and pitch tilt. The output interface RS485 / RS232 / RS422 / TTL are optional.Because of Built in ADI company’s high precision digital temperature sensor that can correct the sensor temperature drift in accordance with the changes of the built-in temperature sensor(temperature output are optional), to ensure high repeatability of the product in the low-temperature and high-temperature environment. The output frequency response most up to 100Hz, for higher response frequency Division we can customize according to the user requests. The products are truly industrial-grade products, reliable performance, scalability. Suitable for a variety of harsh industrial control environment.
