Pneumatic press STA 18/600
punchinghigh-speed

pneumatic press
pneumatic press
pneumatic press
pneumatic press
pneumatic press
pneumatic press
pneumatic press
Add to favorites
Compare this product


Characteristics

Operation
pneumatic
Function
punching
Other characteristics
high-speed
Force

180 kN

Description

Stroke power 180 KN (18 tons) Made in Switzerland, all mechanical parts Adjustable speed 60 - 600 teeth (strokes) per minute up to 10 teeth in one second Equipped with synchronized double rolls feed for strips widths from 5 mm - 160 mm Band saw blades 5 - 160 mm width Maximum saw blade thickness 2.2 mm Teeth pitch up to max. 60 mm adjustable, highly accurate With digital teeth counter Programmable length auto stop Digital speed counter Three working mode: single punch, complete stroke and full automatic Two hands safety start and emergency stop Pneumatic clutch Indexing per minute, infinitely variable 60 - 600 strokes Machine complete weight approx 2 tons Automatic in feed, fully sinchronized with punching moment Comes with strip straightening device on board and strip lubrication (optional) Tool not included Techincal Air 8 bar Operators instruction manual

VIDEO
