CONTINUOUS max. (WRMS) POWER - 500
FREQUENCY (kHz) - 20
CONTINUOUS MODE - yes
PULSE MODE - yes
VOLTAGE (V) - 220-240
OTHER VOLTAGE - on request
DIMENSIONS (LxWxH) - 390x145x148mm
WEIGHT - 4,3kg
START/STOP - Pushbutton/Footswitch
TOUCH SCREEN INTERFACE - LabTablet
COMMUNICATION AND CONTROL - Ethernet
PC-SOFT NexTgen “LabPremium” - optional
TEMPERATURE SENSOR - optional
Max. power: 500WRMS
Frequency: 20kHz
Amplitude setting: 10% – 100%
Control mode: auto-tuned optimum frequency mode
Dimensions (LxWxH): 390x145x148mm
US Start/Stop by Labtablet, dry contact, footswitch
or PC
20 kHz ultrasonic transducer
Diameter: 55 mm
Length: 142 mm
Air cooling input/output
Homogenization
Degassing
Enzyme/ DNA extraction
Emulsification
Reaction acceleration
Bacteria destruction
Sonochemistry
Cell lysis
Extraction
