4 measuring modes (torque, angle of rotation, torque with control variable angle of rotation, angle of rotation with control variable torque)
high-resolution colour graphic display with additional lateral signal lights
free configurable menu structure
optional: Li-ion battery no. 7195-2 and charger no. 7160
3 function modes: triggering, peak hold (indicating operation with peak value display) and track (indicating operation with momentary value display)
Micro-USB interface
Bayonet catch for battery compartment
QuickRelease safety lock - exchange system for insert.wkz.
Data storage (= 2. 500 tightening operations)
up to 200 tightening operations in a maximum of 25 sequence plans are programmable
different tolerance limits can be set depending on the tightening operation
acoustic and visual evaluation of the tightening operation
quick and precise setting via keypad
no unintended adjustment by automatic key lock
overload protection by acoustic and optical warning signal as well as forced release (right)
automatic indication of the next calibration date according to time and/or number of loads
fully automatic calibration and adjustment with the perfectControl® calibration and adjustment device no. 7794-2 (torque) or 7794-3 (torque and angle of rotation)
Units of measurement: N-m, ft-lb, in-lb
automatically correct tightening torque after entering a deviating stitch size
immediately ready for operation again after unloading
Right and left tightening - for left tightening in function mode triggering may be necessary. the insertion tool must be turned by 180°
