Sit-on forklift / electrical / handling / 4-wheel
1 500 kg | SWFE15AC-4F1 SUNWARD INTELLIGENT EQUIPMENT CO.,LTD.

Characteristics

  • Operator:

    sit-on

  • Motor type:

    electrical

  • Function:

    handling

  • Other characteristics:

    4-wheel

Description

Main Parameters

Total weight 2900kg
Rated load capacity 1500kg
Load center 500mm
Max. lifting height of the mast 3000mm
Tilting angle of mast: Forward / Backward 6°/12°
Min. outside turning radius 2023mm
Max. driving speed: No-load 13.5km/h
Max. lifting speed: Full load 300mm/s
Max. gradeability: Full load 10%

Dimensions Parameters
Overall length 2200mm
Overall width 1070mm
Overall height 2056mm
Fork: L×W×T 920×100×35 (mm)
Tire: Front 6.50-10-10PR
Tire: Rear 5.00-8-10PR
Wheel track: Front 893mm
Wheel track: Rear 920mm
Wheelbase 1370mm
Ground clearance 100mm
