Box PC TB-2945-DIN

Intel® Celeron N2930Intel® Celeron Bay Trailquad-core

The TB-2945-DIN fanless box computer is partner to the TB-2945. The major difference is the TB-2945-DIN can be mounted on a DIN rail to save space and integrate seamlessly into your industrial environment. The DIN rail mounting system makes installation a breeze and allows industrial control equipment to be mounted conveniently next to each other. The TB-2945-DIN has an easy-access 2.5” SATA2 HDD Bay, 6 USB ports, and 2 Mini-PCIe expansion slots. This box computer has a wide range 9V to 36V DC power input, and the fanless cooling system allows it to operate in a wide temperature range from 0 to 50 °C (-20 to 60°C optional). The ultra slim design and wall mount make this box PC ideal for industrial control, manufacturing, and machine automation applications. Key Highlights Wide Range DC Power Input (9~36VDC) Steel Chassis with Aluminum Heatsink Ultra Slim, Fanless Design Optional GPIO Edge Computing in Harsh Environments: The TB-2945 Series Box PCs are suitable for edge computing tasks in challenging industrial environments, providing reliable performance and versatile I/O options for real-time data processing. Manufacturing Floor Control Systems: The TB-2945-DIN Box PC, with its DIN rail mounting option, GPIO support, and easy-access SATA2 HDD Bay, is well-suited for manufacturing floor control systems, offering convenient installation, expanded I/O capabilities, and storage flexibility. Digital Signage and Media Players: Featuring dual independent display support and a wide range of I/Os including VGA and HDMI, TB-2845s are excellent choices for digital signage and media player applications
