Disc brake P10 series
pneumatic

disc brake
disc brake
disc brake
disc brake
disc brake
Add to favorites
Compare this product


Characteristics

Type
disc
Operation
pneumatic
Torque

Min.: 0 Nm
(0 ft.lb)

Max.: 58.7 Nm
(43.2949 ft.lb)

Description

The P10 pneumatic brake series provides up to 520 in-lbs (58.7 Nm) of torque at a maximum pressure of 100 PSI. The P10 pneumatic brake series offers single acting and double acting models. • Durable aluminum construction • Replaceable high-grade friction material • Buna-N seals are standard with EPR and Viton® seals as optional • Accommodates disc diameters up to 16 inches (406 mm) • Other options include retractable pistons and floating bracket
