PAHP CARBON Now metal replacement is a reality, super charged carbon fiber.
PAHP CARBON Now metal replacement is a reality, super charged carbon fiber.
PA-HP CARBON 3D PRINTING SPECS
paht carb palla1
DOWNLOAD FULL SPECS PDF
PA-HP CARBON 3D PRINTING PARAMETERS
3d Printing Difficulty
EASY TO
PRINT
3D Printing Plate Tempaerature
PLATE
TEMP. C°
0-45 c°
3D Printing Nozzle Temperature
NOZZLE
TEMP. C°
255° +/-15°
3D Printing Plate Material
PLATE
MATERIAL
Carbon sheet, PA sheet, Plastic film, Composite phenolic cotton
3D Printing Speed
PRINT
SPEED
45 mm/s
It can be your trustworthy industrial companion.
PAHP carbon, metal replacement is real, no others polymers in 3D printing can reproduce the same high modulus, high working temperature and high stress resistance.
Developed to obtain the best layer adhesion, no compromise for metal replacement.
PAHP Carbon, best use for bike and automotive structural component. All components where rigidity and low coefficient of thermal expansion are required.
Low influence from moisture and temperature to measures and electrical properties.
PA-HP CARBON Tips & tricks
0.4 mm is the mininum diameter of the nozzle with carbon fibers reinforced. Carbon fibers are abrasive, we suggest to use a nozzle in hardened or tempered metal, like Widia, or wear resistance internal surface, like ceramics or other. NO tefloned surface!
