Water filter cartridge WE / WS / OS series

oilfinecellulose fiber

The original and still the best. Triple R’s continuous investment in research and development delivers the highest standard of efficiency in oil filtration. Protecting your investments while boosting productivity. Our filter elements are designed to cleanse industrial oils, removing everything from solid particles to water to sludge, varnish and oxidation residues. 3 in 1, all within a single element - a Triple R unique, unmatched by any filter manufacturer worldwide. The filter design forces the oil to flow through 114mm of engineered filter media and creates 3 distinct stages of filtration. The lower part is compressed by a carton box, creating an even finer filter medium. Big particles stay on top of the element. Smaller particles are captured in the upper non-compressed part. The smallest particles are captured in the lower compressed part As big particles are retained on top, the filter becomes an excellent diagnostic tool. The cellulose filter media absorbs water drops and consequently dries the oil to less than 100 ppm. The industry thickest filter, 114mm to flow trough, combined with Triple R's filter media, results in the unique ability for absorbing and removing oil oxidation residues, well known as sludge, or varnish deposits. Features Water absorber The water sponge! Absorbs 900 ml water. Dries oil in 1 pass to below 80 ppm Water separator 1µ for oil 40 cSt. Separates water from oil, based on the coalescence principle. Oil separator 1µ filter element. Separates oil from water, based on the oalescence principle.
