Absolute rotary encoder / Hall effect / CANopen / single-turn
RTP100 TSM SENSORS SRL

Characteristics

  • Type:

    absolute

  • Technology:

    Hall effect

  • Output signal:

    CANopen

  • Construction:

    single-turn, non-contact

  • Protection level:

    IP67

  • Other characteristics:

    high-resolution, miniature, redundant, aluminum

  • Applications:

    for harsh environments

  • Housing diameter:

    40 mm

Description

Description

Hall effect absolute single turn (ø40X8 mm)
CANopen Redundant, Incremental Output

RTP100 is a Very small (40x8mm) contact-less magnetic absolute encoder series featuring high operation speed employed in harsh environments such as, automation and process control fields. Incremental, CANopen and are available, as well as anodized aluminum body material.
RTP100 provide a unique digital code for each distinct angle of the shaft, storing the value of the actual position and, therefore, preventing the loss of information in case of restart of the system or power-loss.
The operating principle of single-turn encoders is magnetic, suitable for industries where elevated speed, IP protection sealing and excellent wear and temperature resistance are needed.
