Chemical PCB etching machine SUNY-ZTM500

chemical PCB etching machine
chemical PCB etching machine
Add to favorites
Compare this product


Characteristics

Type
chemical

Description

Full automatic spray stripping machine Usage: realizing stripping process of the circuit board processing through high pressure spraying and automatic transmission; The machine adopts anticorrosive PVC material, with excellent anti acid and alkali performance; The roof and the front of the machine both have double completely transparent glass windows, so the whole process can be observed With level automatic in board detection function, it can stop automatically in a due time, to make the machine operation more intelligent and automatic With up and down spraying pressure testing and adjustment function, it can make some adjustment to up and down spraying pressure according to the technical requirements; With liquid level instruction window, you can understand the liquid level of the machine in real-time; The machine configures four universal caster wheels for more convenient location adjustment of the equipment; Working mode: PCB automatically in and out board, automatic high pressure spraying up and down double-sided; Work time: 10~240s adjustable; Temperature setting: 20~55°C; Standard volume: 50L; Optional configuration: Ethernet interface, realizing remote diagnosis, monitoring, booking open and close the machine and etc. through the wireless or local area network and the Internet, seamless connection with network management system and software, mating PCB network management software, providing long-term free upgrades service; Power supply: AC380V/9KW Overall dimension: 1400mm×1040mm×1250mm; Net weight: 200KG.

Catalogs

Other U-Therm International (H.K.) Limited products

PCB making machine
