Pneumatic feeder

automatic

Typically a pneumatic transportation system exists of: a condenser (with in- and outlet) a fan a set of tubing a filter Condenser: capacity from 300 kg – 6.000 kg/hr Types: rotary, drum and static condensers Example of a drum condenser Fan: from 5.5 kW up to 110 kW Tubing: designed up to the needs of the customer Filter: sleeve filters (8 sleeves up 200 sleeves – depending on filter capacity needed) Remark: Each material that has to be fed to the press has different characteristics. So each installation needs to be carefully calculated. Depending on quantity of the fiber, distance from the source to the condenser, number of bends in the tubing etc.. we can design the optimal trajectory. As an option we can also integrate metal detection
