SEDM electrical discharge machine QXD 250
high-accuracyCNCflexible

SEDM electrical discharge machine
SEDM electrical discharge machine
SEDM electrical discharge machine
SEDM electrical discharge machine
SEDM electrical discharge machine
SEDM electrical discharge machine
SEDM electrical discharge machine
SEDM electrical discharge machine
SEDM electrical discharge machine
Add to favorites
Compare this product


Characteristics

Type
SEDM
Other characteristics
high-accuracy, CNC, flexible, for PCD tools, 6-axis, with tool changer, with automatic loader, for metalworking tools, tool sharpening, polishing, for woodworking tool
X travel

520 mm
(20 in)

Y travel

970 mm
(38 in)

Z travel

420 mm
(17 in)

Description

QXD 250 – WELL-POSITIONED FOR EVERY CHALLENGE Can you improve on perfection? The new VOLLMER QXD 250 has the answer. With an overall concept refined in many aspects and amazing innovations: Simultaneous path interpolation along six CNC-controlled axes – including the new A-axis Extended travel distances and swivel ranges for tool diameters up to 320 mm and tool lengths up to 250 mm Redesigned main spindle drive for efficient grinding VPulse EDM, the optimum technology for any processing objective Extensive options for flexible adjustment to the specific requirements in the metal or wood tools sector Complete machining in one clamping operation – from measuring to erosion and from grinding to polishing AUTOMATION TOOL CHANGER The right tool is ready every time: The integrated tool changer for up to six different erosion, grinding and polishing discs enables perfect implementation of numerous workpiece variants. WORKPIECE STORAGE An essential component of your automated machining is the right external tool storage. VOLLMER offers you three tried-and-tested solutions here – from a chain magazine to a round magazine: With HC 5 and HC 11, you have two different workpiece storage solutions to choose from. They provide space for up to 28 or 64 workpieces respectively. They can be loaded and unloaded during machining – without delay. That is VOLLMER efficiency. The new double-layered HR holds up to 30 tools in the smallest of spaces – thanks to two levels positioned on top of each other. It enables the automatic machining of tools with different diameters of up to 320 mm. For greater capacity and flexibility.
